High speed motor HM3500

YSA high-speed motor is an industrial-grade high-speed motor series produced by China Chuaneng Automation Co., Ltd., with the following core features:
high performance
Adopting high-strength brushed alloy aluminum body and angular contact bearings, it offers excellent heat dissipation (rated current operating temperature ≤48 ° C), quiet operation (≤38 decibels at 12000 rpm), and high accuracy (radial and axial runout coefficients < 0.01%).
Wide parameter range
: Power coverage from 0.37kW to 0.75kW, rotating speed from 3000rpm to up to 46000rpm (special models), to meet different processing requirements.
reliable protection
All series are equipped with IP54 dust and moisture protection grade, suitable for harsh industrial environments.
diversified application
Applicable to woodworking carving, metal cutting, plastic/PVC processing, precision medical apparatus, electronic appliances and other five industries.
