Electric spindle SM3500

This high-speed cutting motor has the following characteristics
high performance
Adopting high-strength brushed alloy aluminum body and angular contact bearings, it offers excellent heat dissipation (rated current operating temperature ≤48 ° C), quiet operation (12000 rpm noise ≤38 decibels), and high accuracy (radial and axial runout 0.005mm).
Wide parameter range
Power coverage: 0.55kW to 0.75kW, rotating speed from 3000rpm to up to 24000rpm, meeting different processing requirements.
A variety of shaft methods can be customized
: Optical axis, chuck, optical axis with keyway and other types, we can customize production.
reliable protection
All series are equipped with IP54 dust and moisture protection grade, suitable for harsh industrial environments.
diversified application
Applicable to woodworking carving, metal cutting, plastic/PVC processing, precision medical apparatus, electronic appliances and other industries.
